The logical connection function allows flexible input / output expansion.
Partial control and overall control can be constructed.
Employs semiconductor output (excluding expansion units).
Fault diagnosis is possible with detailed LED display.
IEC / EN61508 (SIL3), EN954-1 (Cat.4) and ISO13849-1 (PLe), acquired certification
Obtained UL and CSA certification.
A new type that adds two features is now available in a series.
Off delay time of up to 150 seconds can be set (off delay output is also Cat.4 compatible)
Two logical connection inputs
OMRON Flexible Safety Unit G9SX G9SX-BC202-RT DC24 1pc
Rp4.999.900
Persediaan
Spesifikasi Produk
| Model Number | G9SX-BC202-RT DC24 |
|---|---|
| Unit | 1pc |
| Output | (Safety instantaneous output/safety off-delayed output) P-channel MOS FET transistor output load current When using 1 output: 1 A DC or less, When using 2 outputs: 0.8 A DC or less |
| Function | Single function unit |
| Reset | Input time (reset pressing time) 100 ms or more |
| Ambient Humidity (% RH) | 25-85 (when used) |
| Wiring length | (Maximum of safety input and logic connection input) 100m or less (External connection impedance: 100Ω or less and 10nF or less) |
| Impact Resistance Durability (m/s²) | 300 |
| Operating Voltage | (Safety input / feedback / reset input) DC20.4V to DC26.4V, Internal impedance: Approx. 2.8kΩ |
| Power Consumption (W) | 3 or less |
| Rated Voltage (V) | DC24 |
| Response Time (ms) | (ON → OFF) 15 or less |
| Operating Time | (OFF to ON) When safety input is ON: 50 ms or less |
| Insulation Resistance (MΩ) | Between all terminals and DIN rail: 20 or more DC100V Mega |
| Leakage Current (mA) | (At OFF) 0.1 or less (safety output, auxiliary output) |
| Output Configuration | (Safety instantaneous output) 2 outputs, (auxiliary output) 2 outputs |
| Input Channel | 1ch, 2ch shared |
| Operating Ambient Temperature (°C) | -10 to +55 (with no icing or condensation) |
| M Code | 39071304 |
| Berat (Kg) | 0.1 |
| Tanggal Produk Terdaftar | 27 June 2022 |
| Terakhir Diperbaharui | 01 December 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Peringatan
PERHATIAN: Produk ini dirancang untuk tegangan 100/110/120V (Produk Impor). Penggunaan dengan tegangan yang berbeda dapat mengakibatkan kerusakan atau bahaya, karena tegangan listrik yang umum dipakai di Indonesia adalah 220V.
